Technical specifcations:
Comply with: lEC 61643-11:2011
Location ofUse:sub-distribution cabinet,JP cabinet etc.
Network Systems: TN-S,TN-C.TT
Mode of Protection: L-PE, N-PE, L-PEN, L-N
Protective Elements: High Energy MOV
Max Continuous Operating Voltage (AC) Uc:275/320/385/440 V
Rated Voltage (AC) Un: 220 V
Nominal discharge current(T2) In:20kA
Maximum discharge current lmax: 40kA
Protection level Up(L-N): 1.2/ 1.5/ 1.8/2.0kV
Protection level Up(N-PE)：1.2
Response time:25ns
SPD Special disconnector Recommend：LT-SSD40
TOV N-PE：1200V
Remote communication: With
Remote communication connection:14 11:NO ， 11 12:NC
Remote contact rated current: 220V/0.5A
Mechnical characteristics
connection By screw terminals: 6-25 ㎟
Terminal Screw Torque: 2.0Nm
Recommended Cable cross Section: ≥10 ㎟
Degree of Protection: IP20
Operating temperature: -40 °C~ +70"C
Operating relative humidity: 5%-95%
Working atmospheric pressure: 70kPa ~106kPa
