Product Center

Home / Product Category / Non-insulated and Insulated Terminal Series / Copper Bare Terminal Non-insulated Butt Connector
Copper Bare Terminal
Copper Bare Terminal Copper Bare Terminal
Copper Bare Terminal Copper Bare Terminal

loading

Copper Bare Terminal Non-insulated Butt Connector

Share to:
wechat sharing button
linkedin sharing button
whatsapp sharing button
sharethis sharing button

  • Non-insulated Butt Connector

Availability:
Quantity:
Inquire

Copper Bare Terminal
Product Description
Product Model

Material: Copper

Brezed Sean

Plating: Tin

Item No. Screw dia.(mm) Dimension (mm)
D d L
BN1.25 0.5-1.5 3.3 1.7 15.0
BN2 1.5-2.5 4.0 2.3 15.0
BN3.5 2.5-4 5.0 3.0 15.0
BN5.5 4-6 5.5 3.4 15.0
BN8 10 7.1 4.5 21.0
BN14 16 9.0 5.8 26.0
BN22 25 11.4 7.7 29.0
BN38 35 13.3 9.4 32.0
BN60 50 15.4 11.4 36.0
BN70 70 17.5 13.3 37.0
BN80 95 19.4 14.5 38.0
BN100 120.0 22.0 16.4 38.0
BN150 150 26.5 19.5 54.0
BN180 185 28.5 21.0 57.0
BN200 240 32.5 24.0 63.0
BN325 300 37.0 28.0 72.0
